(3) Program example
Program that restores the offset/gain setting to the A/D converter module
mounted in the position of I/O No. X/Y10 to X/Y1F when M11 is turned OFF.
Control data setting
Offset/gain value restoration
Performs processing at abnormal completion
Dedicated instruction
(GP.OGSTOR)
