3-100
CIRCUIT DIAGRAMS - TEMPERATURE CONTROL
Fully automatic air-conditioning (cont’d)
Air mixing door
motor &
potentiometer
Heater water
temperature
sensor
Air thermo sensor
Cabin temp.
sensor
External air temp.
sensor
Dedicated IC
Dedicated IC
Generic fuse
Internal / External
air switching damper
motor
J/B
(
)
