CIRCUIT DIAGRAMS - POWER DISTRIBUTION
3-21
• ABS
• ACD (vehicle w/out
AYC)
• ACD, AYC
•Intercooler water spray
•Windscreen washer /
wiper
•Turn signal lights,
hazard lights
•Tail lights, position
lights, licence plate
lights, lighting monitor
warning buzzer
•Heater
• Fog lamps
• Full auto A/C
• Headlights
• Headlight levelling
system
• Manual A/C
• Cooling
• ABS
•ACD (vehicle
w/out AYC)
• ACD, AYC
• Sunroof
Windscreen
washer / wiper
Cigarette light,
ashtray
illumination lights
Electric stowable
remote control
door mirrors
•Rear washer /
wiper
•Cabin lights,
boot
compartment
lights, ignition
key cylinder
illumination
light, door ajar
indicator light
• Spare audio
connector
•Clock
• Generic
spare
connector
•Cabin lights,
boot
compartment
lights, ignition
key cylinder
illumination
light, door
ajar indicator
light
