M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
93
IB-1501269-J
(2) CG32 (Machine signal output)
Digital output 32 points (1st station)
(4) CG34 (Machine signal output)
Digital output 32 points (2nd station)
(6) CG36 (Machine signal output)
Digital output 16 points (3rd station)
(8) CJ38 (Machine signal output)
Digital output 32 points (1st station)
(10) CJ40 (Machine signal output)
Digital output 32 points (2nd station)
(11) CJ42 (Machine signal output)
Digital output 32 points (4th station)
[FCU8-DX731 / FCU8-DX750 / FCU8-DX760 / FCU8-DX761]
CG32 CG36
BA BA
20 O Y200 20 O Y210 20 O Y240 20 NC
19 O Y201 19 O Y211 19 O Y241 19 NC
18 O Y202 18 O Y212 18 O Y242 18 NC
17 O Y203 17 O Y213 17 O Y243 17 NC
16 O Y204 16 O Y214 16 O Y244 16 NC
15 O Y205 15 O Y215 15 O Y245 15 NC
14 O Y206 14 O Y216 14 O Y246 14 NC
13 O Y207 13 O Y217 13 O Y247 13 NC
12 O Y208 12 O Y218 12 O Y248 12 NC
11 O Y209 11 O Y219 11 O Y249 11 NC
10 O Y20A 10 O Y21A 10 O Y24A 10 NC
9 O Y20B 9 O Y21B 9 O Y24B 9 NC
8 O Y20C 8 O Y21C 8 O
Y24C 8 NC
7 O Y20D 7 O Y21D 7 O Y24D 7 NC
6 O Y20E 6 O Y21E 6 O Y24E 6 NC
5 O Y20F 5 O Y21F 5 O Y24F 5 NC
4 DOCOM 4 DOCOM 4 DOCOM 4 DOCOM
3 DOCOM 3 DOCOM 3 DOCOM 3 DOCOM
2 DOCOM 2 0V 2 DOCOM 2 0V
1 DOCOM 1 0V 1 DOCOM 1 0V
