Mitsubishi M800S series User Manual

M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
94
IB-1501269-J
[FCU8-DX834]
The input/output assignment is modifiable using a parameter. Refer to "17.6.4.2 Arbitrary Device Assignment"
for details.
<Cable side connector type>
Connector : XG4M-4030 / 7940-6500SC
Strain relief : XG4T-4004 / 3448-7940
Recommended manufacturer : OMRON / 3M
CJ38 CJ40 CJ42
BA BA BA
20 O Y200 20 O Y210 20 O Y220 20 O Y230 20 O Y260 20 O Y270
19 O Y201 19 O Y211 19 O Y221 19 O Y231 19 O Y261 19 O Y271
18 O Y202 18 O Y212 18 O Y222 18 O Y232 18 O Y262 18 O Y272
17 O Y203 17 O Y213 17 O Y223 17 O Y233 17 O Y263 17 O Y273
16 O Y204 16 O Y214 16 O Y224 16 O Y234 16 O Y264 16 O Y274
15 O Y205 15 O Y215 15 O Y225 15 O Y235 15 O Y265 15 O Y275
14 O Y206 14 O Y216 14 O Y226 14 O Y236 14 O Y266 14 O Y276
13 O Y207 13 O Y217 13 O Y227 13 O Y237 13 O Y267 13 O Y277
12 O Y208 12 O Y218 12 O
Y228 12 O Y238 12 O Y268 12 O Y278
11 O Y209 11 O Y219 11 O Y229 11 O Y239 11 O Y269 11 O Y279
10 O Y20A 10 O Y21A 10 O Y22A 10 O Y23A 10 O Y26A 10 O Y27A
9 O Y20B 9 O Y21B 9 O Y22B 9 O Y23B 9 O Y26B 9 O Y27B
8 O Y20C 8 O Y21C 8 O Y22C 8 O Y23C 8 O Y26C 8 O Y27C
7 O Y20D 7 O Y21D 7 O Y22D 7 O Y23D 7 O Y26D 7 O Y27D
6 O Y20E 6 O Y21E 6 O Y22E 6 O Y23E 6 O Y26E 6 O Y27E
5 O Y20F 5 O Y21F 5 O Y22F 5 O Y23F 5 O Y26F 5 O Y27F
4 DOCOM 4 DOCOM 4 DOCOM 4 DOCOM 4 DO
COM 4 DOCOM
3 DOCOM 3 DOCOM 3 DOCOM 3 DOCOM 3 DOCOM 3 DOCOM
2 DOCOM 2 0V 2 DOCOM 2 0V 2 DOCOM 2 0V
1 DOCOM 1 0V 1 DOCOM 1 0V 1 DOCOM 1 0V
CG32 CG34
BA BA
20 O Y200 20 O Y210 20 O Y220 20 OY230
19 O Y201 19 O Y211 19 O Y221 19 OY231
18 O Y202 18 O Y212 18 O Y222 18 OY232
17 O Y203 17 O Y213 17 O Y223 17 OY233
16 O Y204 16 O Y214 16 O Y224 16 OY234
15 O Y205 15 O Y215 15 O Y225 15 OY235
14 O Y206 14 O Y216 14 O Y226 14 OY236
13 O Y207 13 O Y217 13 O
Y227 13 OY237
12 O Y208 12 O Y218 12 O Y228 12 OY238
11 O Y209 11 O Y219 11 O Y229 11 OY239
10 O Y20A 10 O Y21A 10 O Y22A 10 OY23A
9 O Y20B 9 O Y21B 9 O Y22B 9 OY23B
8 O Y20C 8 O Y21C 8 O Y22C 8 OY23C
7 O Y20D 7 O Y21D 7 O Y22D 7 OY23D
6 O Y20E 6 O Y21E 6 O Y22E 6 OY23E
5 O Y20F 5 O Y21F 5 O Y22F 5 OY23F
4 +24V 4 +24V 4 +24V 4 +24V
3 +24V 3 +24V 3 +24V 3 +24V
2 +24V 2 0V 2 +24V 2 0V
1 +24V 1 0V 1 +24V 1 0V
