2-26
Shipping special specifications, options, and maintenance parts
２ Robot arm
(1) Machine cable
（CR2B-574 contoroller only）
■Order type: ● Fixed type 1S-02CBL-1 (2m)
■ Outline
This cable is exchanged for the machine cable (5 m for fixed type) that was supplied
as standard to shorten the distance between the controller and the robot arm.
■ Configuration
Table 2-9 ： Configuration equipments and types
Note) Standard 5 m (for fixed type) is not attached.
[Caution] Orders made after purchasing a robot are treated as purchases of optional equipment. In this case, the
machine cable (5 m for fixed type) that was supplied as standard is not reclaimed.
Please keep it in storage.
Part name Type
Qty. Remarks
Fixed Set of signal and power cables 1S-02CBL-1 1 set 2ｍ
Motor signal cable BKO-FA0741H02 (1 cable)
Motor power cable BKO-FA0768H02 (1 cable)
To Next Page
