3Controller
Magnet contactor control connector output (AXMC) for addition axes
3-57
Fig.3-15 Arrangement figure of the AXMC1 connector (CR2B-574 controller)
Fig.3-16 Arrangement figure of the AXMC1 connector (CR3-535M controller)
<Connector type>
Plug side (user) : FRONT-MSTB2.5/2-STF-5.08
Socket side (controller) : DFK-MSTB2.5/2-GF-5.08
(Connector maker name : Phoenix Contact)
CR2A-572 controller of backside
AXMC1 connector
Enlargement
