3. SPECWICATIONS /MELSEC-A
Error compensation is valid for: manual pulser inching, jogging and
positioning applications.
Backlash compensation, Bc, should be set according to the following
expression:
Bc=BxE
where, B = Actual backlash
E = As above
(1 0) Manual pulser inching travel increment
0 Defines the distance travelled each time a manual pulser inching
command is given.
0 The AD71 counts the number of manual pulser inching com-
mands input and transmits the appropriate number of output
pulses. (The speed is fixed at 2oooO PLS/sec.)
0 During manual pulser inching there is no automatic acceleration/
deceleration.
(1 1 ) Acceleration and deceleration times
0 Defines the period of time from the start of positioning to
when the speed limit value specified in the parameter is reached.
(Refer to Fig. 3.5.)
Parameter speed limit value
4
Positioning speed
- : Swed if starting bias speed
has been set
0,
8
v)
/*
Starting
bias speed Actual
- - - Acceleration and deceleration
-acceleration
time -deceleration time
*
-0
speeds if starting bias speed
Set acceleration time Set deceleration time
Fig. 3.5 Adoration md Ikcrlaration Times
The acceleration and deceleration times cannot be set indepen-
dently.
Acceleration and deceleration are controlled at a constant
value.
When the positioning speed is very much lower than the para-
meter speed limit, the acceleration/deceleration time is com-
paratively short.
Acceleration/deceleration time is valid for zeroing, positioning,
and jog operations.
For interpolation positioning, the acceleration/deceleration
time for the axis with the longer travel is valid. (The acceleration/
deceleration time for the other axis is ignored.)
,
I
3-1 3
--
IB INN €6101-A I
