5. PARAMETERS
5 -  21

Control
mode
No./symbol/
name
Setting
digit
Function
Initial
value
[unit]
P S T
PA18
*MTY
Servo motor
type setting
  When you use a linear servo motor, select its model from [Pr. PA17] and [Pr. PA18].
Set this and [Pr. PA17] at a time.
Refer to the table of [Pr. PA17] for settings.
0000h
  Select a reference range and writing range of the parameter.
Refer to table 5.4 for settings.
00AAh

Table 5.4 [Pr. PA19] setting value and reading/writing range

PA19
*BLK
Parameter
writing inhibit

PA19
Setting
operation
PA PB PC PD PE PF PL


Reading




Other
than
below
Writing



     Reading Only 19

000Ah
Writing Only 19
  Reading



000Bh
Writing


  Reading



000Ch
Writing



Reading




00AAh
(initial
value)
Writing



  Reading



00ABh
Writing


  Reading



100Bh
Writing Only 19
  Reading



100Ch
Writing Only 19
  Reading



10AAh
Writing Only 19
  Reading



10ABh
Writing Only 19

Alarms may not be avoided with the tough drive function depending on the situations of the power supply and load
fluctuation.
You can assign MTTR (During tough drive) to the pins CN1-22 to CN1-25 and CN1-49 with [Pr. PD23] to [Pr. PD26]
and [Pr. PD28].
PA20
*TDS
Tough drive
setting
_ _ _ x  For manufacturer setting  0h
  _ _ x _  Vibration tough drive selection
0: Disabled
1: Enabled

Selecting "1" enables to suppress vibrations by automatically changing setting
values of [Pr. PB13 Machine resonance suppression filter 1] and [Pr. PB15 Machine
resonance suppression filter 2] in case that the vibration exceed the value of the
oscillation level set in [Pr. PF23].
To output the oscillation detection alarm as a warning, set [Pr. PF24 Vibration tough
drive function selection].
Refer to section 7.3 for details.
0h

  _ x _ _  SEMI-F47 function selection
0: Disabled
1: Enabled

Selecting "1" enables to avoid occurring [AL. 10 Undervoltage] using the electrical
energy charged in the capacitor in case that an instantaneous power failure occurs
during operation. In [Pr. PF25 SEMI-F47 function - Instantaneous power failure
detection time], set the time period until the occurrence of [AL. 10.1 Voltage drop in
the control circuit power].
0h
  x _ _ _  For manufacturer setting  0h
