16. USING A DIRECT DRIVE MOTOR
16 - 1
16. USING A DIRECT DRIVE MOTOR
CAUTION
When using the direct drive motor, read "Direct Drive Motor Instruction Manual".
POINT
The direct drive servo system is available for the servo amplifiers of which
software version is A5 or later.
16.1 Functions and configuration
16.1.1 Summary
The fields of semiconductor/LCD manufacturing systems, mounters, and others have strong demands for
high accuracy and efficiency. Therefore, the number of systems using a direct drive motor for a drive axis
has been increasing. The direct drive servo system includes the following features.
(1) Performance
(a) The direct drive servo system ensures the high-rigidity and the high-torque. A high-resolution
encoder enables the high-accuracy control.
(b) The high-resolution encoder contributes to the high-accuracy indexing.
(c) Since reducer is no longer required, no backlash occurs. In addition, the settling time is reduced, and
the high-frequency operation is enabled.
(d) Since reducer is no longer required, the motor does not deteriorate with time by reducer.
(2) Mechanism
(a) The motor's low profile design contributes to compact moving part of the machine and a low center
of gravity for enhanced equipment stability.
(b) The motor has an inner rotor with hollow shaft which enables cables and pipes to be passed
through.
(c) Lubrication and the maintenance due to abrasion are not required.
The following shows the differences between the direct drive motor and the rotary servo motor.
Differences
Category Item
Direct drive motor Rotary servo motor
Remarks
Motor pole
adjustment
Magnetic pole detection Required Not required
(default setting)
Automatically executed at the first
servo-on after the power is turned
on.
For the absolute position detection
system, [Pr. PL01] can disable the
magnetic pole detection. (Refer to
(2) (b) of 16.3.3.)
Absolute position
detection system
Absolute position encoder
battery
Required Required
Absolute position storage
unit
(MR-BTAS01)
Required Not required
