11. OPTIONS AND AUXILIARY EQUIPMENT
11 - 52
11.7 MR Configurator2
POINT
MR-J4-_A_-RJ servo amplifier is supported with software version 1.19V or later.
MR Configurator2 (SW1DNC-MRC2-E) uses the communication function of the servo amplifier to perform
parameter setting changes, graph display, test operation, etc. on a personal computer.
11.7.1 Specifications
Item Description
Project Create/read/save/delete project, system setting, and print
Parameter Parameter setting, axis name setting, parameter converter (Note 1)
Monitor Display all, I/O monitor, graph, and ABS data display
Diagnosis
Alarm display, alarm onset data, drive recorder, no motor rotation, system configuration, life
diagnosis, machine diagnosis, fully closed loop diagnosis (Note 2), and linear diagnosis (Note 3)
Test operation
Jog operation (Note 4), positioning operation, motor-less operation (Note 5), DO forced output,
and program operation, test mode information
Adjustment One-touch tuning, tuning, and machine analyzer
Others Servo assistant, parameter setting range update, help display
Note 1. This is available only in the standard control mode.
2. This is available only in the fully closed loop control mode.
3. This is available only in the linear servo motor control mode.
4. This is available in the standard control mode, fully closed loop control mode, and DD motor control mode.
5. This is available only in the standard control mode. This will be available in the fully closed loop control mode,
linear servo motor control mode, and DD motor control mode in the future.
