13. PARAMETER LIST
Item Parameter No. Description
I/O Assign – Set the mounting status of each module.
Slot setting
Classification
4000
H Set the module type, number of points, head I/O No., etc.
Number of points
Start XY
Model Name
Base setting
Power model name
4001
H
Set model names of a power supply module and/or extension
cables.
This setting does not affect CPU module operation.
Extension cable
MELSECNET/Ethernet setting –
Set link parameters for the MELSECNET (II) data link system,
network parameters for the MELSECNET/10 network system or
Ethernet parameters.
Unit count 5000
H
Valid module for
access to other station
5001
H
MELSECNET (II)
and MELSECNET/
10 network setting
Inter-device transfer
parameters
5002
H
Routing parameter 5003H
Network setting 5NM0H
Network refresh
parameter
5NM1
H
Common parameter 5NM2H
Station inherent
parameter
5NM3
H
I/O assignment 5NM4H
Ethernet network
setting
Group No.
9N00
H
IP address
