13 - 7
13. PARAMETER LIST
* N means the number of the master module counting from the first. (N: 1 to 8)
Item Parameter No. Description
MELSECNET/MINI setting –
Make the settings for automatic refresh of the MELSECNET/MINI
system.
Number of master modules 6000
H Set the number of MELSECNET/MINI master modules to be used.
MELSECNET/
MINI
detailed settings
Master module head
I/O No.
600N
H*
Make the detailed setting required for automatic refresh of the
MELSECNET/MINI system.
Model name & number
of stations
Receive data
batch refresh
Send data
batch refresh
Retry count for
communication errors
FROM/TO instruction
access priority
Receive data clear
at communication error
Faulty station detection
bit data
Error No.
MINI link operation
when CPU stopped
Circuit error check
Supplementary settings
7000
H
Perform various settings required when multiple programs are
used.
Program setting Set programs to be executed among multiple programs.
Boot file setting Set the file for boot operation and other settings.
SFC –
Perform various settings required for SFC programs.
SFC program start mode 8002
H
Start condition 8003H
Output mode when the block is stopped 8005H
Acknowledge XY assignment –
Allows confirmation of the settings made in I/O assignment.
This setting does not affect CPU module operation.
To Next Page
