Chapter Two: Installation Interface Cables
21
System Interface Cables
(Continued)
To Connect the 247 Unit To... Use the MKS Cable...
Standard Shielded
250 Controller (PCS) CB247-2-3 CB247S-2-3
1250 Controller (PCS) CB247-9-3 CB247S-9-3
247 Readout CB247-4-x*** CB247S-4-x***
* To connect the 1150, 1151, or 1152 unit to a 260 PS-1, you must also use cable
CB260(S)-3-10.
** An extra power supply is needed if using more than two 1559 MFCs with one 247 unit. Use
cable CB1559(S)-1-10 to connect the 247 unit to a 260 PS-1 Power Supply.
*** x = length in feet.
Table 5: System Interface Cables
