Chapter Two: Installation Setu
29
Remote Flow Control
Remote flow control can be accomplished using TTL logic control. Interface connector P6
provides the means to remotely turn the flow on/off and to adjust and monitor the flow rate in
any channel using a set point signal from a voltage applied to P6. Refer to Table 7, page 32, for
the pinout for Interface connector P6.
