6. Turn the flow ON by placing the FLOW CONTROL SWITCH to the ON position.
The set point signal is applied to the MFC, the Flow Indicator LED illuminates, and flow
begins after a slight delay. The correct flow is realized within approximately 1.5
seconds, depending on the type of MFC being used.
Note
The flow through any channel can be displayed on the Digital Panel
Meter by placing the Channel Selector Switch to that channel.
7. Turn the flow OFF by placing the FLOW CONTROL SWITCH to the OFF position.
