3. Charging
TheEVASystemincludestwocomponents:theopticalunitandmobiledevice.Eachneedstobecharged
separately.

2Ports30W/6A
Achargerappropriateforover150countriesisprovided,inordertoallowforchargingindifferentcountries.

Power:30W
Input:100240V
Output:3A*2
Technology:iSmart
Weight:100g
Dimensions:50mm*43mm*42mm
Certification:CE/FCC/UL/LVD

3.1. ChargingtheOpticalUnit
3.1.1. Tochargetheopticalunit,connecttheMicroUSBchargertotheunit’srightsidechargingport.Connect
thecabletoawallsocketwiththeproperUSBelectricalportadapter.

(figure11)

3.1.2. ThechargerincludedhastwoslotsforUSBstoallowcharginginasingleelectricaloutlet.
3.1.3. TheChargeIndicatorLightscanbefoundabovethechargingportonthefrontoftheopticalunit.When
connectedtothecharger,thelightswillturnonandturngreenwhilecharging.


PleaseNote:Thecolposcopecannotbeusedwhilecharging,astheLEDlightwillnotbeabletobeswitched
on.

3.1.4. Chargeindicatorlights–operationmode
