16. Appendix5:Qualityframe

AbouttheQualityframe
TheQualityframeisanAIbasedtoolthatdetectsthepresenceofacervixwithinthescreenoftheEVA
device.Itthenassessestheimagetoseeiftheimagequalitymeetsthecriteriatobedesignatedasuitable
imageforvisualinspectionofthecervix.

16.1. UsingtheQualityframe
16.1.1. Thequalityframefeatureguidesuserstocapturehighqualitycervicalimages.Whenturnedonthis
featurepresentsagreyorgreenframeonthescreenoftheEVAdeviceduringvisualization/image
capture.
16.1.2. Agreenframeindicatesthatquality(acombinationoffocus,imagequalityandpositioningofthecervix
intheimage)isexcellent.Agreyframeindicatesusablequalityforcervicalexamination.Incaseno
cervixisbeingidentifiedbythecamera,noframewillappear
16.1.3. Userscancaptureimagesorvideoatanypointregardlessofthequalityfameindication.


