7.3. Illumination
Thecervixshouldbefullyilluminatedandwithoutglare.

TheLEDlightispoweredbyarechargeablebatterycontainedwithintheopticalunit.Thebatteryhas
chargecapacitysufficientforapproximately10hoursofcontinualuse.

7.3.1. Thecolposcopereducesglarewithapolarizer,howeverglarefromthespeculumreflectionisstill
possible.Ifthisisthecase,repositionthecolposcopeand/orthespeculumuntilthereislessglare. 
7.3.2. Whenholdingthecolposcope,makesurenottoblocktheLEDlightwithyourfinger.
  
(figure17)    (figure18)

7.4. Focus
Therearetwowaystoadjustthecolposcopefocus.

7.4.1. Thefirstistoadjustthedistancebetweenthecolposcopeandthepatient.Onceyouhaveachieved
adequatefocus,asyouzoominandoutdigitallyyoucanusethefinefocuswheelatthetipofthelens
toreadjustyourfocus.
7.4.2. Therecommendeddefaultsettingforthefinefocuswheelistobefullyextended.Ifworkingata
distancewhichnormallyyieldstheclearestimagesdoesn’twork,youcantryadjustingthefinefocus
wheelsothatthelensmovesinandoutuntilthecorrectfocusisfound.

