Figure 3: External Fuse Holder & 2A Fuse
2.1.4 3M VHB Surface Cleaner
The 3M VHB Surface Cleaner supplied with Mobileye 6 Cleans and degreases the
Windshield surface to ensure optimum adhesion for 3M VHB Tape provided with the
Mobileye 6 Main Unit.
Figure 4: 3M VHB Surface Cleaner
2.1.5 Mobileye 6 Connection Scheme
Figure 5: Mobileye 6 connection scheme with EyeCAN
