Unit on the rear view mirror or place it on the dashboard before passing the
cable behind the vehicle trimmings).
3. Firmly connect the appropriate wire from the Mobileye 6 (CAB000205) to the
identified vehicle signal.
Each wire in the Mobileye 6 cable mentioned above has a unique color.
Make sure to connect the correct vehicle signal to its appropriate wire
according to Table 2-7.
Identified vehicle signal
Vehicle battery (Constant 12V~24V) via 2A Fuse
1 Analog signal (Brake, Wipers or High Beams), or
both analog Left and Right Turn indicator signals via
Diode (Connection description for AUX wire can be found in
Appendix B)
NOTE: Make sure the 2A fuse is kept easily accessible
NOTE
NOTE: Always check the Mobileye Internal Database for CAN-Bus availability before
Installation is started
4. Keep the Mobileye 6 EyeCAN and EyeWatch connectors easily accessible.
3.2.3 Installing the EyeWatch (optional)
1. Select the optimal location for the EyeWatch. The unit should be placed on
the dashboard at a location which is in the driver's field of view and
convenient for him to see when driving, and to allow him access to the
controls while seating comfortably in the driver's seat (the EyeWatch
mounting angle is adjustable by the installer, a Philips screw driver is
required).
2. Clean the selected location with the provided 3M VHB Surface cleaner.
