Mobileye 6 Technical Installation Guide_Rev0.3
Feb, 2016
Page 8 of 65
Mobileye Proprietary and Confidential
support@mobileye.com
2 Mobileye 6 Description
WARNING: The Mobileye 6™ system should be installed ONLY by Mobileye® Technologies Ltd.
authorized personnel!
2.1 Mobileye 6 Components overview
The Mobileye 6 is based on the following elements:
The Mobileye 6 Main Unit and Connector Cable (Camera)
The EyeWatch Display & Control Unit
The Mobileye Enhancement-Box (E-box) (Optional add-on)
The Mobileye CAN-Sensor (Optional add-on)
When receiving the Mobileye 6 please verify receiving & identify all the following
components:
2.1.1 Mobileye 6 Main Unit & connecting cable (CAB000205)
The Mobileye 6 Main Unit contains the following components:
Camera unit, High-quality Audio Alert Buzzer, Mobileye Chip on Board system (SeeQ)
and Connector Cable.
