2.2.2 External Fuse Holder & 2A Fuse – 2 pieces
The External Fuse Holder connection is as follows
1. Cut the fuse holder cable so that it creates 2 separate wires
2. Connect one end of the Fuse holder to the Vehicle Power source (12V/24V).
3. Connect one end of the 2
nd
fuse holder to the vehicle ignition source (12V/24V).
4. Connect the available end of the Fuse holder wire to the Mobileye Power Cable
(Red wire) or the vehicle ignition source (Blue wire).
2.2.3 EyeWatch – Display & Control unit connection
The EyeWatch is connected to the Mobileye 6 EyeWatch Female connector (J1) using
the EyeWatch connecting cable Male connector (J1).
Wire Name
Wire color
Connector
Connection To
EyeWatch Cable (CAB000087)
Black
J1 - male
Mobileye 6 cable - EyeWatch connector
EyeWatch - (CAB000205)
Black
J1- female
EyeWatch Display & Control unit
Table 2: EyeWatch connections
2.2.4 EyeCAN – Mobileye CAN to USB interface
The EyeCAN is NOT part of the Mobileye 6 system. It is a tool which enables the
installer to configure and calibrate the Mobileye 6 system during the installation. The
Mobileye 6 EyeCAN Male connector (P2) is used for connection with the Mobileye
EyeCAN Box Female connector (J5).
Wire Name
Wire color
Connector
Connection To
CAN (EyeCAN box connector)
Black
J5 - female
Mobileye 6 cable - EyeCAN connector
EyeCAN - (CAB000205)
Black
P2- Male

Table 3: EyeCAN connections
2.2.5 E-box Connections
For information regarding E-box connection please see Appendix E.
