Mobileye 6  Technical Installation Guide_Rev0.3
Feb, 2016
Page 31 of 65
Mobileye Proprietary and Confidential
support@mobileye.com
4.2.3 Signals Source
- The Signal source slide informs you about the source of each signal.
- CAN-Bus signals can be configured back to work with an Analog connection.
- A vehicle must be chosen from the CAN Database us
- Signals not available by CAN will either be disabled, AUX or Analog.
- When connecting the AUX wire to 1 Analog (or the L & R indicators together), the

- It is recommended not to make any changes if you followed the instructions in the

