Mobileye 6 - Camera Calibration (TAC); Click on Calculate Close TAC

Technical Support
Mobileye 6  Technical Installation Guide_Rev0.3
Feb, 2016
Page 34 of 65
Mobileye Proprietary and Confidential
support@mobileye.com
4.2.6 Camera Calibration (TAC)
NOTE: at
1. Locate the TAC Target exactly in the middle of the vehicle's front bumper, as
close as possible to the bumper.
2. For Trucks and Buses with No Front Engine Hood (flat nose) locate the TAC
Target exactly 1 meter from the middle of the vehicle's front bumper (verify
exact middle position be using any flat 1 meter pole).
4.2.7 Click on “Calculate Close TAC”.
