9.5 E-box Technical Specifications
E-box unit
Physical Characteristics
Length:
90mm
Width (without lens):
58mm
Height:
25mm
Weight:
50g
Color:
Black
Case Material:
Plastic
Electrical Characteristics
Input Voltage:
4.5-5.5VDC
Input current:
5V 50mA
Limited Power source
200mA max at normal and single fault conditions
Environmental Characteristics
Operating Temperature:
-20°c to +85°c
Storage Temperature:
-40°c to +105°c
Signals Input Support
Signal Name
Direction
Electric Spec
Speed
Input
3.3-28V / 0-1KHz
Hi-Beam
Input
3.3-28V / Logic Level
Brake
Input
3.3-28V / Logic Level
Left Winker
Input
3.3-28V / Logic Level
Output (active Low)
Output
Open collector 3.3-28V (100mA max)
Wiper
Input
3.3-28V / Logic Level
Output (active Low)
Output
Open collector 3.3-28V (100mA max)
Right Winker
Input
3.3-28V / Logic Level
Hi-Beam
Input
3.3-28V / Logic Level
Signals Input – High Voltage (Pos)
3.3v  28v
Signals Input – Low Voltage (Neg)
< 2.8v
Mobileye 6 to A-box Cable (CAB000131)
Cable Length:
400mm
Cable Diameter:
4mm
A-box I/O Signals Cable (CAB000133)
Cable Length:
650mm
Cable Diameter (each):
24 AWG
