Power Input:
The CAN-Sensor power inpu
Pin 1 +5Vdc (Red wire)
Pin 3 GND (Black wire)
CAN-bus Output:
The CAN High and CAN Low output wires are the twisted pair of wires:
CAN High: White wire (labeled CAN B H)
CAN Low: Yellow wire (labeled CAN B L)
