Installing the Wall Mount
Drilling Template Wall Mount
Notes
Use the drilling template available on www.mobotix.com, Support > Download
Center > Documentation > Drilling Templates.
Make sure that the drilling template is not scaled or adjusted to the paper size when
printing the PDF le (enlarged or reduced).
Direct installation over
surface- and ush-
mounted sockets
Depth: 201 mm/7.91 in
Height: 125 mm/4.92 in
Width: 216 mm/8.50 in
