31
Preparing the Installation
2.1.2 Mounting Options
On-Wall Installation (MX-OPT-AP)
The On-Wall Set can reliably protect external cables if the cables cannot
be fed in the center below the camera housing. The On-Wall Mount also
provides ample space for extra modules.
On-Wall Installation with 10° Inclination (MX-OPT-AP-10DEG)
This On-Wall Set is identical to the regular On-Wall Set, except that the
mounted camera is inclined by 10 degrees. The inclination makes it
possible for the camera to deliver the best images even in demanding
situations.
In-Ceiling Installation (MX-OPT-IC)
The In-Ceiling Set allows the D26 camera to be installed in suspended
ceilings, for example. This type of installation provides optimal protection
for the camera and reduces the visible prole to a minimum since only
the dome remains visible.
Vandalism Set (MX-D26-Vandal)
The Vandalism Set provides added protection for D26 cameras. The
set consists of a robust stainless steel cover and an impact-resistant
polycarbonate dome. A camera equipped with the Vandalism Set is
perfectly suited for applications in demanding environments (such as
prisons, trouble areas, train stations, etc.).
Wall Mount (MX-OPT-WH)
The Wall Mount is the ideal solution for mounting the D26 to walls for
indoor and outdoor applications. The camera is completely dust-proof
and resistant to water jets (IP65). The Wall Mount also covers RJ45 ush-
mounted sockets and has ample space for additional modules.
Corner and Pole Mount (MX-OPT-MH)
The MOBOTIX Corner and Pole Mount is the ideal choice when mounting
the MOBOTIX D26 to a pole or building corner. This mount can only be
used in conjunction with the Wall Mount. For poles with a diameter
ranging from 60 to 180 mm.
On-Wall Set (IP65, for
outdoor applications)
10° On-Wall Set (IP65, for
outdoor applications)
Discreet in-ceiling
installation; decorative
outer ring also available
in stainless steel
Vandalism Set (IP65)
Wall Mount made from
sturdy PBT-30GF (IP65)
Outdoor Corner and Pole
Mount made from stain-
less steel (in conjunction
with Wall Mount)
