Mobotix M73 - Hardware

Hardware
Feature Properties
Image sensor (color or B&W sensor) up to 4K UHD 3840x2160, 16:9, 1/1,8”
Light sensitivity
n
Color sensor (day): 0,1 lx @ 1/60s; 0,005 lx @ 1s
n
BW sensor (night): 0,02 lx @ 1/60s; 0,001 lx @ 1s
Exposure control Manual and automatic mode
1s to 1/16,000s
Video codecs
n
H.264, H.265 with Triple Streaming
n
MxPEG+
n
MJPEG
IK protection class IK10 (housing)
IPprotection class IP66
Operating temperature range –40 to 65°C/–40 to 149°F
Min. cold start temperature –30°C/–22°F
Relative Humidity 95% non-condensing
Internal DVR, out of the box MicroSD card (8GB), MxPEG+ recording only
I/Os see Connector Box LSA / Connector Box RJ45, p. 33
Microphone/Speaker
n
Functional audio module, max. 4.5Watt (see Functional Modules, p.
32)
n
Microphone Sensitivity: -35 +/-4dB (0dB = 1V/pa, 1kHz)
n
Speaker: 0.9W at 8Ohm
Passive infra-red sensor (PIR) Available with functional module, max. 4.5Watt (see Functional Modules,
p. 32)
Infra-red illumination Three functional modules for wide-angle, standard, and tele lenses
Range of infra-red illumination Up to 30m/100ft (may be more depending on scene)
Shock detector (tamper detection) Yes
Max. power consumption 25W
