Connector Box RJ45 Connector Box LSA
Fig. 36: Installed and ready for Connector Box RJ45
Fig. 37: Installed and ready for Connector Box LSA
Mounting to a Pole
CAUTION! Before mounting the camera, make sure that a network connection with power supply according
to the PoE Plus (802.3at-2009) standard is available at the mounting position (see Connecting the Camera
to the Network, p. 70).
CAUTION! The mounting pole should have a diameter between 60 and 180 mm.
Dimensions MOBOTIX M73 pole mount
Fig. 38: Dimensions M73 pole mount – rear view
Mounting
Mounting Options
64 / 110
