Installing the Security Clips
CAUTION! To prevent module rotation or removal it is highly recommended to install the security clips.
The security clips M.14, p. 21 are protecting the sensor modules or the blind module in
the front plate of the MOBOTIX M73 against theft and unwanted rotation (e.g., due to
vibration when mounted on a pole or in an automotive scenario).
CAUTION! Do not use the plastic nuts delivered with the sensor modules to lock the modules in place!
Fig. 16: Do not use plastic nut!
Mounting
Installing the Sensor Modules
