Mobotix M73 - Sensor Modules; Features ECO Thermal Image Sensor

Sensor Modules
Features ECO Thermal Image Sensor
Feature Properties
Thermal sensitivity Typ. 65 mK, IR range 7.8 to 14 µm
Temperature measurement
range
-40 to 330°C/ –40 to 626°F
Field of view T040: 105 x 75°; 5,23mr, focal 2.2mm, f/1.05
T080: 56 x 42°; 3,00mr, focal 4.0mm, f/1.00
Thermal image sensor Uncooled microbolometer,
CIF: 320 x 240 pixels
Dimensions 58 x 42.5 mm (dia. 50 mm), 65g
Pixel pitch 12μm
Max. image size Can be scaled up to 3072x2048 (6MP), automatically scaled to size of MX Sensor module
Max. frame rate 9fps (when displaying an Mx Sensor module and a thermal sensor module, the overall frame
rate of the camera is reduced to 9fps)
Operating temperature -40° to +65°C / 40° to 149°F;
5% to 95% non-condensing
Power consumption 600mW
IP rating IP66
IK rating IK04
Material PBT-30GF (housing); Chalcogenide (lens)
Software (included) Video management software MxManagementCenter
