Mobotix M73 - Mounting Options; Mounting to a Wall

Mounting
Mounting Options
Mounting Options
You can mount the MOBOTIX M73 to any even surface on a wall or to poles with up to 180mm/7.1" diameter
using the stainless steel pole mount that is available as accessory. The concealed cabling improves security of
the installation.
CAUTION! Installation only on flat surface! Unevenness must not exceed 0.5mm/0.02in!
Only use genuine MOBOTIX patch cables to guarantee the weatherproofness!
The mounting plate C.1 has been dimensioned to fully cover conventional flush-mounted sockets (without
frame) or cavity sockets.
NOTE! Before mounting the camera, determine its ideal position and make sure that the field of view is not
obstructed in any way. Once the camera has been mounted, you can fine-tune the image. If the monitored
area changes or the camera has to be installed in a different location, you can simply exchange the sensor
modules.
Mounting to a Wall
Before mounting the camera, make sure that a network connection with power supply according to the PoE
Plus (802.3at-2009) standard is available at the mounting position (see Connecting the Camera to the Net-
work, p. 70).
NOTE! Download the drilling template from the MOBOTIX website: www.mobotix.com> Support > Down-
load Center > Marketing & Documentation> Drilling Templates.
CAUTION! Always print or copy the drilling template at 100% of the original size!
NOTE! Do not use the dowels if the installation surface is wood. Only use the screws to fasten the mounting
plate directly on the surface. In order to facilitate screwing in wood, the positions should first be pre-drilled
using a 2mm drill bit, for example (drilling depth just slightly less than screw length).
Tiltability when mounted to a wall:
n
horizontally: 2 x 180 degrees
n
vertically: 110degrees
59 / 110
