Mobotix M73 - Connector Box LSA; Connector Box RJ45

Functional Module Order Code Remark
 Mx-F-WLA-T for Tele Lens Sensor Modules 15° and 30°
  Power consumption White Light Modules:
3,2 W at 100% brightness.
Connector Box LSA / Connector Box RJ45
Interface Properties
Network 100/1000 Mbps
Allowed cable dimensions
for cables connected to the
PCB terminals
Conductor cross section 
AWG 20 - 26
Rigid 0.14mm
2
- 0.5mm
2
Flexible 0.14mm
2
- 0.5mm
2
Flexible with ferrule 0.25mm
2
- 0.34mm
2
Line In Standard Line In: (0dB) Vrms=1V
Line Out Headphones with 20mW @ 16 Ohm or 32 Ohm.
Audio inputs as a Line Out function to 10k Ohm impedance of receiver. Audio level while con-
nected to 10k Ohm equals -10dbV
IN /OUT INPUT
n
Contact Closure (no galvanic isolation necessary) or up to 50V AC/DC
n
max. length for cables: 50m
OUTPUT
n
requires pull-up resistor and external power supply (10mA /max. 50V DC - no AC)
n
Output may be loaded with max. 50mA
n
max. length for cables: depends on loop impedance of the connected cable.
