32
M26 Camera Manual: Installation
Allround View
Thanks to its hemispheric lens, a single
M26 can monitor an entire room right
including the four corners (360° Allround
View). The camera’s ideal position is on
the ceiling in the center of the room.
Rooms with a square oor area of up to
approx. 40 m² (48 yd²) in general allow
recognizing details even at the borders
of the full image. If you would only like
to know if persons enter a room or for
monitoring specic objects, rooms with
more than 100 m² (120 yd²) oor area
can be monitored using a single camera.
1.50m/5
3m/10
2.5to3.5m/8to11.5
5m/16.4
Identication Recognition Perception
Camera focus (best image quality)
MOBOTIX recommendation
MOBOTIX original image of
180° panorama (B016 lens)
2.5to3.5m/8to11.5
Mounting at the center of the wall
Image quality (precision) diminishes as the distance of
an object to the camera focal point increases:
1 very good, 2 good, 3 satisfactory
Captures an entire room
