M26 Camera Manual: Operating the Camera
Ceiling-Mounted:SetNorth(User-DenedNorthDirection)
Once the camera has been mounted on to the ceiling, you need to specify its North direction.
This is not the ”true” direction of North but rather the main line of sight or the focus of the
camera or sensor module. It serves as a reference for the North direction in the Surround and
Double Panorama display modes (the Ceiling option was already selected in the Installation
Type Quick Control).
1. In the case of a double image, click on the corresponding sensor module (camera
image) and select the Normal option from the Display Mode Quick Control.
2.
Rotate the live image in the desired direction using the mouse or a joystick connected
to the computer.
vPTZ
For vPTZ use and the
conguration of a USB
joystick, see Section 3.3.1
