B CLASSIC / B FUTURA / S CLASSIC - TECHNICAL MANUAL
SERVICE MENU
SERVICE MENU – MPX CALIBRATION
SQ37
Menu - MPX CALIBRATION lets you correct any differences between the
pressure value displayed and the pressure measured with a reference
pressure gauge.
The three counters displayed can be modied and represent:
- P+ pressure value correction at +2.10 bar
- P0 pressure value correction at 0 bar
- P- pressure value correction at –0.80 bar
In order to determine whether the pressure value displayed is accurate,
you will need to connect the pressure transducer to an external device
capable of reproducing the 3 control conditions:
- P+ positive pressure +2.10 bar
- P0 atmospheric pressure 0.00 bar
- P- negative pressure –0.80 bar
The device must be equipped with a reference pressure gauge to allow a
comparison with the displayed pressure value.
The displayed value can be changed in 0.001 bar steps.
SERVICE MENU – 134°C STERILIZATION
SQ38
Select 134°C STERILIZATION to display a screen where it is possible to
select the sterilisation time between 4 and 5.5 minutes. This option is valid
only for sterilisation cycles performed at 134°C, except for Prion cycle.
Select one of the two values with the arrows then conrm with
OK.
