Sterilizers SUPREME - FUTURA - CLASSIC (17-22-28)
- TECHNICAL MANUAL
GUIDELINES - SAFETY TEST - VALIDATION (IF REQUIRED)
3.3. APPLICATION EXAMPLE WITH INSTRUMENT SECUTEST SIII+ ON STERILIZER
OR THERMODISINFECTOR
Measurement of earth conductor resistance
Measurement of earth-leakage current
Measurement of insulation resistance between network and earth
Disconnect power supply cable of the device and connect it to the relevant instrument socket (e.g.: SECUTEST
SIII+). Activate the device to be tested.
NOTE: the device under test must be on and must be pre-heated in advance through an operating cycle
of at least 30 minutes, until it reaches the operating temperature, as required by the Standard.
Select the type of test with reference to standard IEC 61010, from PC or tester screen. Follow the instructions
displayed with reference to the visual check and device data entry (e.g.: serial number).
Power up the device and select the Standard.
INITIAL SETTING
CONNECTIONS WITH THE MACHINE POINTS MUST BE KEPT FOR THE TESTS DESCRIBED
BELOW.
NOTE: follow the instructions requested by the control instrument.
E.G.: SECUTEST SIII+ instrument connection
