Mocom SUPREME 17 - Service Menu; Autoclaves with Root Valve REF.7 A24, 7 A34, 7 A44, 7 A54

Sterilizers SUPREME - FUTURA - CLASSIC (17-22-28)
- TECHNICAL MANUAL
38
SERVICE MENU
EN
5. SERVICE MENU
5.1. AUTOCLAVES WITH ROOT VALVE REF.7A24, 7A34, 7A44, 7A54
FUNCTION AVAILABLE ON THE
DEVICE
FUNCTION AVAILABLE IN THE APP
FUNCTION NOT AVAILABLE ON THE
DEVICE
FUNCTION NOT AVAILABLE IN THE
APP
SQ1 – ACCESSING THE SERVICE MENU
From the home screen, select the gear icon and then
the SERVICE menu.
SQ2 – ENTER PIN
Enter the PIN 6626
SQ3 – SERVICE MENU
The SERVICE menu offers the following options:
Component test
Sensor calibration
Test cycles
Initial settings
User management
REF input
SN input
