Mocom SUPREME 17 - 3 rd Vacuum Phase

Sterilizers SUPREME - FUTURA - CLASSIC (17-22-28)
- TECHNICAL MANUAL
26
FUNCTIONING
EN
4.7. 3rd VACUUM PHASE
This phase too, which precedes the PROCESS phase, includes the direct steam and condensate drainage followed
by a forced decrease down to - 0.80 by means of the vacuum pump.
In order to make it easier to reach the value of -0.80 bar, also solenoid valve EV2 is activated for 5”.
3
st
VACUUM PHASE - component activation status
STATUS
EV1
High
drain
(N.O.)
EV2
Air inlet
(N.C.)
EV3
Low drain
(N.C.)
EV4
Drain
deflector
(3V)
EV5
Chamber
air inlet
(N.C.)
FAN
WATER
PUMP
- EV6
VACUUM
PUMP
CHAMBER TUBE
BUNDLE
HEATING
ELEMENT
GENERATOR
HEATING
ELEMENT
Direct
steam
drainage
Off
open
Off
closed
Off
closed
Off (2)
Off
closed
ON
OFF
ON
ON
ON
Direct
condensate
drain
On
closed
Off
closed
On
open
Off (2)
Off
closed
ON
OFF
ON
ON
ON
Decrease
from 0.10
to -0.80 bar
On
closed
On
open
On
open
On (1)
Off
closed
ON
OFF
ON
ON
ON
134° C B Cycle - 4’00’’
