Input and Output Cable Connection
For normal I/Os, use shielded cables. Connect the shield of the cable to one of the grounding screws. Recommended cable
LiYCY size min. 0.14 mm².
Solid State Output
In case the second cable gland is used for the normal I/Os, use one cable and cable gland for the power supply and solid state
relay. Recommended cable size min. 0.75 mm².
USE SEPARATE CABLE INLETS FOR CABLES CONNECTED TO THE SOLID STATE RELAY OUTPUT AND CABLES CONNECTED
TO THE OTHER INPUT/OUTPUTS.
IN MULTIPHASE NETS, SOLID STATE RELAY SHOULD HANDLE ONLY THE SAME PHASE THAT IS USED FOR POWERING
THEMETER.
ATTENTION
UTILISEZ DES ENTRÉES DE CÂBLE DISTINCTES POUR LES CÂBLES BRANCHÉS À LA SORTIE DES RELAIS STATIQUES ET
AUX CÂBLES BRANCHÉS AUX AUTRES ENTRÉES OU SORTIES.
POUR LES FILETS MULTIPHASES, LE RELAIS STATIQUE NE DEVRAIT SERVIR QUE LA MÊME PHASE UTILISÉE POUR
ALIMENTER LE COMPTEUR.
