Miscellaneous Menu
Miscellaneous
Power Up The number of times that the unit has been powered on.
Settling Time Measures settling of coils and must be less than one quarter of the excitation period. Zero ms if no
detector is connected.
Language This parameter allows changing the current language. English is the default setting.
The following languages are supported:
German (Deutsch), Czech (Cestina), Spanish (Espanol), French (Francais), Russian (России),
Italian (Italiano).
Date Set date of the system in the format day, month, year [DD.MM.YY] used for data logging.
Time Set time of the system in the format hour, minutes, seconds [HH.MM.SS] used for data logging.
EEPROM Delete all data logging information from the EEPROM.
Polar Voltage Measure electrode polarizing voltage in ± V (only for service purpose).
Display Rotation The Display can be rotated to 0°, 90°, 180° and 270°.
Contrast The contrast of the display can be adjusted between 14 (low) and 49 (high).
Datalog Period The data logging period can be adjusted to the following increments:
• Every 15 min / 1 h / 6 h / 12 h / 24 h
There is a 500 kB memory available with about 30,000 data records for data logging. The logging
capacity is as follows (Uni-directional mode):
Time Period Duration
15 min up to 312 days
1 h up to 1250 days
6 h up to 20 years
12 h up to 40 years
24 h up to 80 years
Startup, configuration, and error events that are logged can reduce the data logging capacity. Logging
in Bi-directional mode reduces the logging capacity by about 40%.
The logging information can be downloaded by a PC program, which can be ordered with the following
part number: 67354-010.
Log Off, On and Preset
Information Menu
Info
Serial Number Serial number of the electronic board.
Version Software version of the device.
Compilation Date Date of the software version.
OTP CRC Checksum of the software update.
Application CRC Checksum of the application.
M1000 Main Menu Programming Options
Page 33 March 2020 MAG-UM-00379-EN-07
