ModMAG M1000 - Food Grade Detector Specifications; Tri-Clamp Connection Details; DIN 11851 Connection Details; BS4825;ISO2852 Standard Dimensions

Size
A Std*
in.
(mm)
A
ISO**
in.
(mm)
B1
in.
(mm)
B2
in.
(mm)
ANSI Flanges DIN Flanges
Finish
Est. Wt.
lb (kg)
D
in. (mm)
K
in. (mm)
d2×n
in. (mm)
D
in. (mm)
K
in. (mm)
d2×n
in. (mm)
Inches DN
1/4 in. 6
6.69
(170)
—
8.98
(228)
10.08
(256)
3.50
(88.9)
2.37
(60.3)
0.63 × 0.16
(15.9 × 4)
3.54
(90)
2.37
(60)
0.55 × 0.16
(14 × 4)
9.04
(4.1)
5/16 in. 8
6.69
(170)
—
8.98
(228)
10.08
(256)
3.50
(88.9)
2.37
(60.3)
0.63 × 0.16
(15.9 × 4)
3.54
(90)
2.37
(60)
0.55 × 0.16
(14 × 4)
9.04
(4.1)
3/8 in. 10
6.69
(170)
—
8.98
(228)
10.08
(256)
3.50
(88.9)
2.37
(60.3)
0.63 × 0.16
(15.9 × 4)
3.54
(90)
2.37
(60)
0.55 × 0.16
(14 × 4)
9.04
(4.1)
1/2 in. 15
6.69
(170)
7.87
(200)
9.37
(238)
10.47
(266)
3.50
(88.9)
2.37
(60.3)
0.63 × 0.16
(15.9 × 4)
3.74
(95)
2.56
(65)
0.55 × 0.16
(14 × 4)
9.04
(4.1)
3/4 in. 20
6.69
(170)
7.87
(200)
9.37
(238)
10.47
(266)
3.87
(98.4)
2.75
(69.8)
0.63 × 0.16
(15.9 × 4)
4.13
(105)
2.95
(75)
0.55 × 0.16
(14 × 4)
11.24
(5.1)
1 in. 25
8.86
(225)
7.87
(200)
9.37
(238)
10.47
(266)
4.25
(107.9)
3.13
(79.4)
0.63 × 0.16
(15.9 × 4)
4.53
(115)
3.35
(85)
0.55 × 0.16
(14 × 4)
16.76
(7.6)
1-1/4
in.
32
8.86
(225)
7.87
(200)
9.96
(253)
11.06
(281)
4.63
(117.5)
3.50
(88.9)
0.63 × 0.16
(15.9 × 4)
5.51
(140)
3.94
(100)
0.71 × 0.16
(18 × 4)
18.96
(8.6)
1-1/2
in.
40
8.86
(225)
7.87
(200)
9.96
(253)
11.06
(281)
5.00
(127)
3.87
(98.4)
0.63 × 0.16
(15.9 × 4)
5.91
(150)
4.33
(110)
0.71 × 0.16
(18 × 4)
20.06
(9.1)
2 in. 50
8.86
(225)
7.87
(200)
9.96
(253)
11.06
(281)
6.00
(152.4)
4.75
(120.6)
0.75 × 0.16
(19 × 4)
6.50
(165)
4.92
(125)
0.71 × 0.16
(18 × 4)
24.47
(11.1)
2-1/2
in.
65
11.02
(280)
7.87
(200)
10.67
(271)
11.77
(299)
7.00
(177.8)
5.5
(139.7)
0.75 × 0.16
(19 × 4)
7.28
(185)
5.71
(145)
0.71 × 0.16
(18 × 4)
50.92
(23.1)
3 in. 80
11.02
(280)
7.87
(200)
10.67
(271)
11.77
(299)
7.50
(190.5)
6.00
(152.4)
0.75 × 0.16
(19 × 4)
7.87
(200)
6.30
(160)
0.71 × 0.31
(18 × 8)
53.13
(24.1)
4 in. 100
11.02
(280)
9.84
(250)
10.94
(278)
12.05
(306)
9.00
(228.6)
7.50
(190.5)
0.75 × 0.31
(19 × 8)
8.66
(220)
7.09
(180)
0.71 × 0.31
(18 × 8)
55.34
(25.1)
5 in. 125
15.75
(400)
9.84
(250)
11.73
(298)
12.83
(326)
10.00
(254)
8.50
(215.9)
0.87 × 0.31
(22.2 × 8)
9.84
(250)
8.27
(210)
0.71 × 0.31
(18 × 8)
56.44
(25.6)
6 in. 150
15.75
(400)
11.81
(300)
12.20
(310)
13.31
(338)
11.00
(279.4)
9.50
(241.3)
0.87 × 0.31
(22.2 × 8)
11.22
(285)
9.45
(240)
0.87 × 0.31
(22 × 8)
58.64
(26.6)
8 in. 200
15.75
(400)
13.78
(350)
13.31
(338)
14.41
(366)
13.5
(342.9)
11.75
(298.4)
0.87 × 0.31
(22.2 × 8)
13.39
(340)
11.61
(295)
0.87 × 0.47
(22 × 12)
85.10
(38.6)
10 in. 250
19.69
(500)
17.72
(450)
14.25
(362)
15.35
(390)
16.00
(406.4)
14.25
(361.9)
1.00 × 0.47
(25.4 × 12)
15.55
(395)
13.78
(350)
0.87 × 0.47
(22 × 12)
—
12 in. 300
19.69
(500)
19.69
(500)
16.73
(425)
17.83
(453)
19.00
(482.6)
17.00
(431.8)
1.00 × 0.47
(25.4 × 12)
17.52
(445)
15.75
(400)
0.87 × 0.47
(22 × 12)
—
14 in. 350
19.69
(500)
21.65
(550)
17.72
(450)
18.82
(478)
21.00
(533.4)
18.75
(476.2)
1.13 × 0.47
(28.6 × 12)
19.88
(505)
18.11
(460)
0.87 × 0.63
(22 × 16)
—
16 in. 400
23.62
(600)
23.62
(600)
18.70
(475)
19.80
(503)
23.5
(596.9)
21.25
(539.7)
1.13 × 0.63
(28.6 × 16)
22.24
(565)
20.28
(515)
1.02 × 0.63
(26 × 16)
—
18 in. 450
23.62
(600)
—
19.69
(500)
20.79
(528)
25.00
(635.0)
22.75
(577.8)
1.25 × 0.63
(31.7 × 16)
24.21
(615)
22.24
(565)
1.02 × 0.79
(26 × 20)
—
20 in. 500
23.62
(600)
—
20.67
(525)
21.42
(554)
27.50
(698.5)
25.00
(635.0)
1.25 × 0.63
(31.7 × 16)
26.38
(670)
24.41
(620)
1.02 × 0.79
(26 × 20)
—
Standard
ANSI flanges 1/4…8 in. (DN 6…200) Pressure 150 lbs
DIN flanges
1/4…8 in. (DN 6…200) Nominal Pressure 232 psi (16 bar)
10…20 in. (DN 250…500) Nominal Pressure 145 psi (10 bar)
* Standard
**ISO 13359
Specications
Page 41 March 2020 MAG-UM-00379-EN-07
