Length of bracket > 1500 mm ( > 60 inch.):
Side support should be mounted to all brackets
positioned perpendicular to the rail in a Straight
rail system and to both primary rails in a Traverse
system.
Side support should be mounted to the first and
last bracket positioned parallel to the rail in a
Straight rail system. Traverse Systems need one
Side support parallel to each Primary rail end.
Straight Rail System
Traverse System
