♦ Inhibit Lines
The Inhibit inputs define whether a programmed coin will be accepted or not.
Which coins are affected by the inhibit inputs is decided in conjunction with the
Bank Select inputs. (See next section).
If the Inhibit pin is not connected OR High then the corresponding coin will be
inhibited i.e. Rejected.
If the Inhibit pin is Low then the corresponding coin will be accepted if deemed
to be true.
NB: The default setting is for ALL inhibit inputs to be High and therefore coins
are inhibited.
