Money Controls SR5 - Environmental Operating Specifications

SR5 Technical Manual TSP010.doc Issue 3.0 - October 2001
CONFIDENTIAL
Not to be disclosed without prior written permission from Money Controls
Page 45 of 50
♦ Specified EMC Performance
Emissions
This product is compliant with EMC test specification EN55022; 1998
Immunity
This product is compliant with EMC test specification EN55014-2; 1997
Shock / Vibration Immunity
This product is compliant with BS 2011 part 2.1. [ IEC 68-2-27 ]
♦ Environmental specification
Table 14: Environmental Ranges
Operating temperature range:
0°C to 55°C 10% to 75%
RH non-condensing
Storage temperature range:
-20°C to 70°C 5% to 95%
RH non-condensing
(Recovery time by the acceptor after a temperature step change is 1
hour per 20°C. Maximum operating rate of change 20°C per hour.)
♦ Material Flammability Rating
The major plastic part of the SR5 (the body) is rated as UL94-V0
The other parts are rated as UL94-HB
The 8-way manifold is rated as UL94-HB
