The following error codes are supported.
Table 11: Error Codes
Code Error
1 Reject coin
2 Inhibited coin
3 Multiple window ( ambiguous coin type )
6 Accept sensor timeout
8 2nd close coin error ( coin insertion rate too high )
14 Accept sensor blocked
15 Sorter opto blocked
17 Coin going backwards
23 Credit sensor reached too early
24 Reject coin ( repeated sequential trip )
25 Reject slug
35 Number of coin meter pulses overloaded
36 Games overloaded
254 Coin return mechanism activated ( flight deck open )
The following fault codes are supported.
Table 12: Fault Codes
Code Fault
1 EEPROM checksum corrupted
2 Fault on inductive coils
3 Fault on credit sensor
4 Fault on piezo sensor
8 Fault on sorter exit sensors
22 Fault on thermistor
34 Temperature outside operating limits
The following status codes are supported.
Table 13: Status Codes
Code Status
1 Coin return mechanism activated ( flight deck open )
