SECTION TWO – WIRING AND INSTALLATION
DS2000 USER’S MANUAL (rev.C)
2.25
2.11.2.4 ENCODER OUTPUT CONNECTOR (J2C)
Encoder simulated output are available on the J2C connector. The conductors are
fastened by insertion, opening the connector using a screwdriver.
• Mating connector: insertion type, 6 pin (Moog code AK4716).
Pos. Name Function
1 ■ A+ Encoder output: A channel
2 A- Encoder output: A channel denied
3 B+ Encoder output: B channel
4 B- Encoder output: B channel denied
5 C+ Encoder output: C channel
6 C- Encoder output: C channel denied
Tab. 2.19 – J2C encoder output connector
