MC824H is an electronic control unit for the automation of swing gates.
IMPORTANT! – Any other use than as specified herein or in environ-
mental conditions other than as stated in this manual is to be consid-
ered improper and is strictly prohibited!
The control unit is ready for connection to devices belonging to the Opera sys-
tem, the Bluebus system and the Solemyo solar energy supply system.
If powered from the mains, it can house a buffer battery (model PS324, option-
al accessory), which ensures that the automation can perform a number of
manoeuvres for several hours in the event of a power failure.
Other available accessories include the dedicated receivers with “SM” fitting
(SMXI, OXI, etc.).
PRODUCT DESCRIPTION AND
INTENDED USE
1
Safety warnings
• IMPORTANT! – This manual contains important instructions and warn-
ings for personal safety. Incorrect installation could cause serious physical
injury. Read all parts of the manual carefully before starting work. If in doubt,
interrupt installation and contact the Nice Service Centre for clarifications.
• IMPORTANT! – Important instructions: keep this manual in a safe place
to enable future product maintenance and disposal procedures.
• IMPORTANT! – Under the latest European legislation, automatic door
and gate installations must be compliant with the standards specified
in Directive 2006/42/EC (formerly 98/37/EC) (the Machinery Directive)
and the standards EN 12445, EN 12453, EN 12635 and EN 13241-1 in
particular, which enable conformity of the automated functionality to
be de clared. In the light of the above, all work involving installation,
connection, testing and maintenance of the product must be carried
out exclusively by qualified and competent technicians!
Installation warnings
•Before commencing installation, check that the product is suitable for the
intended kind of use (see paragraph 2.2 “Limits of use” and “Product technical
specifications”). If not suitable, do NOT proceed with installation.
•The contents of this manual refer to a standard system as described in fig. 2a.
•All installation and maintenance work must be carried out with the
au to mation system disconnected from the electricity supply. If the
power discon nection device cannot be seen from where the automation sys-
tem is po sitioned, then before starting work a notice must be attached to the
disconnection device bearing the words “CAUTION! MAINTENANCE IN PRO-
GRESS”.
•On the power line to the system, install a device for disconnection from the
power mains with a gap between contacts that assures complete disconnec-
tion in the conditions of overvoltage category III.
•Connectthecontrolunittoanelectricpowerlineequippedwithanearthing
system.
•Duringinstallation,handletheproductwithcare,avoidingtheriskofcrushing,
impact,droppingorcontactwithanytypeofliquid.Neverplacetheproduct
near sources of heat or expose to naked flames. This may damage prod-
uct components and cause malfunctions, fire or hazardous situations. If this
oc curs, suspend installation immediately and contact the Nice Service Centre.
•Nevermakemodificationstoanypartoftheproduct.Operationsotherthanas
specified can only cause malfunctions. The manufacturer declines all liability
for damage caused by makeshift modifications to the product.
•Theproduct’spackagingmaterialsmustbedisposedofinfullcompliance
with local regulations.
Safety warnings
•Theproductshouldnotbeusedbychildrenorpeoplewithimpairedphysical,
sensorialormentalcapacitiesorwhohavenotreceivedadequatetrainingin
the safe use of the product.
•Inthevicinityoftheautomationchildrenmustbesupervisedtoensurethat
they do not play with it.
•Donotallowchildrentoplaywiththefixedcontroldevices.Keepremote
control devices out of the reach of children.
GENERAL SAFETY WARNINGS AND PRECAUTIONS
2.1 - Preliminary checks for installation
Before proceeding with installation, check the condition of the product compo-
nents, suitability of the selected model and conditions of the intended installa-
tion environment:
•Ensurethatallmaterialusedisinperfectconditionandsuitableforuse.
•Ensurethatallconditionsofuseremainwithinthelimitsofproductapplica-
tion (paragraph 2.2) and within the limit values stated in the “Product techni-
cal specifications”.
•Ensurethattheselectedinstallationenvironmentiscompatiblewiththeover-
all dimensions of the product (fig. 1).
•Ensurethattheselectedsurfacesforproductinstallationaresolidandguar-
antee a stable fixture.
INSTALLATION
2
